Rated Power 2400W 24VDC Solar Inverter

The DC inverter with a rated power of 2400 watts is suitable for application scenarios with relatively large power requirements. It is capable of converting DC power (24 volts) to AC power to power various electronic devices and home appliances. The high rated power of 2400 watts can meet the needs of some large home appliances and industrial equipment, such as refrigerators, washing machines, air conditioners, etc. It has high efficiency and reliability, and can provide stable power output.

Rated Power 2400W 24VDC Solar Inverter Details

Rated Power 2400W 24VDC Solar Inverter High-efficiency output

The rated output power is 2400VA/2400W, which can provide stable and reliable power supply for home and office environments.

Rated Power 2400W 24VDC Solar Inverter Solar charging function

The maximum solar charging current is 80A, and the maximum PV input power is 2400W, which can make full use of solar resources to charge the battery and improve energy utilization efficiency.

Rated Power 2400W 24VDC Solar Inverter Multiple protection measures

with overcharge, overdischarge and overload protection functions to ensure the safe operation of batteries and inverters and prolong the life of equipment.

Rated Power 2400W 24VDC Solar Inverter Multifunctional communication interface

support USB, RS232, GPRS and WIFI communication interface, convenient for monitoring and remote control, and realize intelligent management.

Rated Power 2400W 24VDC Solar Inverter Strong adaptability

a wide range of optional input voltage, suitable for different power environments, frequency range of 50Hz/60Hz, to meet the needs of various electrical equipment.

Specification of Rated Power 2400W 24VDC Solar Inverter

ModelRaisun RSI44-2.4KW
Maximum PV Input Power2400W
Rated Output Power2400VA/2400W
Maxium Solar Charging Current80A
Selectable Voltage Range170~280VAC(For Personal Computers)
90~280VAC(For Home Appliances)
Frequency Range50Hz/60Hz(Auto sensing)
AC Voltage Regulation(Batt.Mode)230VAC±5%
Surge Power4800VA
Efficiency(Peak) PV to INV98%
Efficiency(Peak) Battery to INV94%
Transfer Time10 ms(For Personal Computers); 20ms(For Home Appliances)
Battery Voltage24VDC
Floating Charge Voltage27VDC
Overcharge Protection33VDC
Maximum AC Charge Current60A
Maximum PV Array Power3000W
MPPT Range Operating Voltage90~400VDC
Maximum PV Array Open Circuit Voltage450VDC
Maximum Charging Current80A
Maximum Efficiency98%
Dimension, D×W×H348*270*95mm
Net Weight(kgs)5
Comumication InterfaceUSB/RS232/GPRS/WIFI
Mumidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature0℃ ~ 55℃
Storage Temperature-15℃ ~ 60℃
