Rated Power 1500W 12VDC Battery Inverter

The Rated Power 1500W 12VDC Battery Inverter is a lower-power inverter designed for converting DC power from a 12V battery into AC power. It has a maximum rated power output of 1500 watts, which makes it suitable for powering smaller electrical devices and appliances. This inverter is commonly used in automotive applications, off-grid cabins, camping setups, and smaller backup power systems. It provides a convenient and efficient way to utilize DC power from a 12V battery source for running AC-powered devices.

Rated Power 1500W 12VDC Battery Inverter Details

Rated Power 1500W 12VDC Battery Inverter Charging function

The inverter has a charging function and can receive DC power from solar panels for charging. The maximum solar charging current is 80A, and the maximum PV array power is 2000W. This enables the system to use solar energy resources for environmentally friendly battery charging.

Rated Power 1500W 12VDC Battery Inverter Stable output voltage

Inverter provides a stable 230VAC±5% AC output voltage in battery mode to ensure the normal operation of connected devices. The stability of this output voltage can meet the needs of various household appliances and office equipment.

Rated Power 1500W 12VDC Battery Inverter Communication interface

The inverter has a variety of communication interfaces, including USB, RS232, GPRS and WIFI. Through these interfaces, users can easily perform remote monitoring and control with the inverter, and know the system status, parameters and battery charging status in real time.

Rated Power 1500W 12VDC Battery Inverter Size

The physical size of the inverter is 348*270*95mm, and the weight is 4kg. It has a compact design and light weight, suitable for installation in environments with limited space.

Rated Power 1500W 12VDC Battery Inverter Solar charger

The inverter is equipped with a solar charger function, which supports a maximum solar charging current of 80A and a maximum PV array power of 2000W. This enables the inverter to efficiently utilize solar charging to provide a sustainable energy supply for off-grid or hybrid energy systems.

Specification of Rated Power 1500W 12VDC Battery Inverter

ModelRaisun RSI44-1.5KW
Maximum PV Input Power1500W
Rated Output Power1500VA/1500W
Maxium Solar Charging Current80A
Selectable Voltage Range170~280VAC(For Personal Computers)
90~280VAC(For Home Appliances)
Frequency Range50Hz/60Hz(Auto sensing)
AC Voltage Regulation(Batt.Mode)230VAC±5%
Surge Power3000VA
Efficiency(Peak) PV to INV98%
Efficiency(Peak) Battery to INV94%
Transfer Time10 ms(For Personal Computers); 20ms(For Home Appliances)
Battery Voltage12VDC
Floating Charge Voltage13.5VDC
Overcharge Protection16VDC
Maximum AC Charge Current60A
Maximum PV Array Power2000W
MPPT Range Operating Voltage90~400VDC
Maximum PV Array Open Circuit Voltage450VDC
Maximum Charging Current80A
Maximum Efficiency98%
Dimension, D×W×H348*270*95mm
Net Weight(kgs)4
Comumication InterfaceUSB/RS232/GPRS/WIFI
Mumidity5% to 95% Relative Humidity(Non-condensing)
Operating Temperature0℃ ~ 55℃
Storage Temperature-15℃ ~ 60℃
