The battery pack boasts a cycle life exceeding 5000 cycles, ensuring long-lasting performance and durability.
Offers SOC (State of Charge) accuracy of less than 8%, allowing precise monitoring of the battery's charge level.
It is rated IP54 for dust and water resistance, ensuring reliable operation in different environmental conditions.
The cooling system is natural, and it supports communication through RS232, RS485, and CAN interfaces.
The battery pack is certified with MSDS, UN38.3, RoHS, and CE, compliance with safety and environmental standards.
The cells adopt the safest lithium iron phosphate (LiFePO4) battery, saving costs.
Battery capacity can be easily increased based on usage requirements.
Allows for the combination of different battery packs according to energy storage needs.
Lighter weight compared to lead-acid batteries.
No explosion risk, with built-in BMS for safety.
| Model | Raisun RSB61-48V 85Ah |
| Battery Type | LifePO4 |
| Typical Capacity(Ah) | 85Ah |
| Typical Voltage(V) | 48V |
| Connection | 2P15S |
| Voltage Working Range(V) | 40.5V-54.75V |
| Working Temperature(℃) | Charge: 0℃ ～ +55℃ Discharge: -20℃ ～ +60℃ |
| Storage Temperature(℃) | -20℃ ～ +35℃ |
| Nominal Capacity(kWh) | 4.08kWh |
| Max. Charge Current(A) | 70A |
| Max. Discharge Current(A) | 75A |
| Cycle Life | ＞5000 |
| SOC Accuracy | ＜8% |
| Weight(kg) | 49kg |
| Dimensions(mm) | 185×450×580mm |
| IP Grade | IP54 |
| Transportation SOC | 30% |
| Cooling | Nature |
| Communication | RS232, RS485, CAN |
| Certifications | MSDS, UN38.3, RoHS, CE |
